Alluminio - Condensatori polimerici
| Foto: | Numero parte produttore | Disponibilità | Prezzo | Quantità | Scheda tecnica | Packaging | Series | ProductStatus | Type | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Ratings | Applications | Features | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PCR1C471MCL1GSCAP ALUM POLY 470UF 20% 16V SMD Nichicon |
202 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | PCR | Active | Polymer | 470 µF | ±20% | 16 V | 22mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | - | 2.2 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.315 (8.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
PCX1E121MCS1GSCAP ALUM POLY 120UF 20% 25V SMD Nichicon |
490 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | PCX | Active | Polymer | 120 µF | ±20% | 25 V | 29mOhm | 3000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | - | 2.2 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.433 (11.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
PCV1H680MCL1GSCAP ALUM POLY 68UF 20% 50V SMD Nichicon |
200 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | PCV | Active | Polymer | 68 µF | ±20% | 50 V | 29mOhm | 3000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2.6 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.500 (12.70mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
63SXV39MCAP ALUM POLY 39UF 20% 63V SMD Panasonic Electronic Components |
354 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | OS-CON™, SXV | Active | Polymer | 39 µF | ±20% | 63 V | 25mOhm | 1000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | 46.5 mA @ 120 Hz | 930 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.472 (12.00mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
PLV1E271MDL1TDCAP ALUM POLY 270UF 20% 25V T/H Nichicon |
205 | - |
RFQ |
Scheda tecnica |
Cut Tape (CT),Tape & Box (TB) | PLV | Not For New Designs | Polymer | 270 µF | ±20% | 25 V | 25mOhm | 3000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2.8 A @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
PLX1H270MDL1TDCAP ALUM POLY 27UF 20% 50V T/H Nichicon |
698 | - |
RFQ |
Scheda tecnica |
Cut Tape (CT),Tape & Box (TB) | PLX | Active | Polymer | 27 µF | ±20% | 50 V | 33mOhm | 3000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | - | 2 A @ 100 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.472 (12.00mm) | - | Through Hole |
|
PCR1C681MCL1GSCAP ALUM POLY 680UF 20% 16V SMD Nichicon |
3,847 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | PCR | Active | Polymer | 680 µF | ±20% | 16 V | 19mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | - | 3.2 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.394 (10.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
MAL218297604E3CAP ALUM POLY HYB 220UF 25V SMD Vishay Beyschlag/Draloric/BC Components |
183 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | 182 CPHZ | Active | Hybrid | 220 µF | ±20% | 25 V | 27mOhm | 10000 Hrs @ 105°C | -55°C ~ 105°C | - | Automotive | - | - | 2.3 A @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.425 (10.80mm) | 0.315 L x 0.315 W (8.00mm x 8.00mm) | Surface Mount |
|
870055775007CAP ALUM POLY 68UF 20% 50V T/H Würth Elektronik |
2,059 | - |
RFQ |
Scheda tecnica |
Cut Tape (CT),Tape & Box (TB) | WCAP-PTHR | Active | Polymer | 68 µF | ±20% | 50 V | 35mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 100 mA @ 120 Hz | 2 A @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.551 (14.00mm) | - | Through Hole |
-V.jpg)
|
HZA227M025F24VT-FCAP ALUM POLY HYB 220UF 25V SMD Cornell Dubilier Electronics (CDE) |
108 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | HZA_V | Active | Hybrid | 220 µF | ±20% | 25 V | 27mOhm | 10000 Hrs @ 105°C | -55°C ~ 105°C | AEC-Q200 | Automotive, Bypass, Decoupling | - | 230 mA @ 120 Hz | 2.3 A @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
80SXV47MCAP ALUM POLY 47UF 20% 80V SMD Panasonic Electronic Components |
449 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | OS-CON™, SXV | Active | Polymer | 47 µF | ±20% | 80 V | 28mOhm | 1000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | 49 mA @ 120 Hz | 980 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.500 (12.70mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
HZA277M035G24T-FCAP ALUM POLY HYB 270UF 35V SMD Cornell Dubilier Electronics (CDE) |
413 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | HZA | Active | Hybrid | 270 µF | ±20% | 35 V | 20mOhm | 10000 Hrs @ 105°C | -55°C ~ 105°C | AEC-Q200 | Automotive, Bypass, Decoupling | - | 250 mA @ 120 Hz | 2.5 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.413 (10.50mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
HZA337M025G24T-FCAP ALUM POLY HYB 330UF 25V SMD Cornell Dubilier Electronics (CDE) |
3,320 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | HZA | Active | Hybrid | 330 µF | ±20% | 25 V | 20mOhm | 10000 Hrs @ 105°C | -55°C ~ 105°C | AEC-Q200 | Automotive, Bypass, Decoupling | - | 250 mA @ 120 Hz | 2.5 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.413 (10.50mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
875075655006CAP ALUM POLY 150UF 20% 35V SMD Würth Elektronik |
3,105 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | WCAP-PSLC | Active | Polymer | 150 µF | ±20% | 35 V | 25mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 190 mA @ 120 Hz | 3.8 A @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.472 (12.00mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
MAL218397005E3CAP ALUM POLY HYB 270UF 35V SMD Vishay Beyschlag/Draloric/BC Components |
3,917 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | 183 CPHT | Active | Hybrid | 270 µF | ±20% | 35 V | 20mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | - | Automotive | - | - | 2 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.425 (10.80mm) | 0.394 L x 0.394 W (10.00mm x 10.00mm) | Surface Mount |
|
PPC802M016FG2SAACAP ALUM POLY 8000UF 16V CHAS Cornell Dubilier Electronics (CDE) |
2,154 | - |
RFQ |
Scheda tecnica |
Box | PPC | Active | Polymer | 8000 µF | ±20% | 16 V | 6mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | 16 A @ 120 Hz | 18 A @ 20 kHz | - | - | 6.250 L x 5.000 W (158.75mm x 127.00mm) | 0.039 (1.00mm) | - | Chassis Mount |
|
URP1C471MP30811ERUCONDUCTIVE POLYMER SOLID CAPACIT Chinsan (Elite) |
1,000 | - |
RFQ |
Scheda tecnica |
Cut Tape (CT),Tape & Box (TB) | URP | Active | Polymer | 470 µF | ±20% | 16 V | 11mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 5.4 A @ 100 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
URP0J152MP51012UCONDUCTIVE POLYMER SOLID CAPACIT Chinsan (Elite) |
800 | - |
RFQ |
Scheda tecnica |
Cut Tape (CT),Tape & Box (TB) | URH | Active | Polymer | 1500 µF | ±20% | 6.3 V | 12mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 5.56 A @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.531 (13.50mm) | - | Through Hole |
|
RSA1A121MCN1GSCAP ALUM POLY 120UF 20% 10V SMD Nichicon |
4,995 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | FPCAP, RSA | Active | Polymer | 120 µF | ±20% | 10 V | 18mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 290 mA @ 120 Hz | 2.9 A @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.236 (6.00mm) | 0.256 L x 0.256 W (6.50mm x 6.50mm) | Surface Mount |
|
|
RSA0J331MCN1GSCAP ALUM POLY 330UF 20% 6.3V SMD Nichicon |
61,853 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | FPCAP, RSA | Active | Polymer | 330 µF | ±20% | 6.3 V | 14mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 316 mA @ 120 Hz | 3.16 A @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.236 (6.00mm) | 0.256 L x 0.256 W (6.50mm x 6.50mm) | Surface Mount |
