Alluminio - Condensatori polimerici
| Foto: | Numero parte produttore | Disponibilità | Prezzo | Quantità | Scheda tecnica | Packaging | Series | ProductStatus | Type | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Ratings | Applications | Features | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
-Photo-Taped-Size-G.jpg)
|
EEH-AZC1J560BCAP ALUM POLY 56UF 20% 63V T/H Panasonic Electronic Components |
3,052 | - |
RFQ |
Scheda tecnica |
Cut Tape (CT),Tape & Box (TB) | ZC | Active | Hybrid | 56 µF | ±20% | 63 V | 30mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 210 mA @ 100 Hz | 1.4 A @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.413 (10.50mm) | - | Through Hole |
-Photo-Taped-Size-G16.jpg)
|
EEH-AZS1H221BCAP ALUM POLY 220UF 20% 50V T/H Panasonic Electronic Components |
2,150 | - |
RFQ |
Scheda tecnica |
Cut Tape (CT),Tape & Box (TB) | ZS | Active | Hybrid | 220 µF | ±20% | 50 V | 14mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 555 mA @ 100 Hz | 3.7 A @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.657 (16.70mm) | - | Through Hole |
-Photo-Taped-Size-G.jpg)
|
EEH-AZK1E471BCAP ALUM POLY 470UF 20% 25V T/H Panasonic Electronic Components |
3,593 | - |
RFQ |
Scheda tecnica |
Cut Tape (CT),Tape & Box (TB) | ZK | Active | Hybrid | 470 µF | ±20% | 25 V | 20mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 420 mA @ 100 Hz | 2.8 A @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.413 (10.50mm) | - | Through Hole |
-Photo-Taped-Size-G.jpg)
|
EEH-AZT1E331BCAP ALUM POLY 330UF 20% 25V T/H Panasonic Electronic Components |
3,517 | - |
RFQ |
Scheda tecnica |
Cut Tape (CT),Tape & Box (TB) | ZT | Active | Hybrid | 330 µF | ±20% | 25 V | 16mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 525 mA @ 100 Hz | 3.5 A @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.413 (10.50mm) | - | Through Hole |
|
EEH-ZU1V471PCAP ALUM POLY HYB 470UF 35V SMD Panasonic Electronic Components |
2,804 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | ZU | Active | Hybrid | 470 µF | ±20% | 35 V | 9mOhm | 4000 Hrs @ 135°C | -55°C ~ 135°C | AEC-Q200 | Automotive | - | 825 mA @ 100 Hz | 5.5 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.661 (16.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
EEH-ZU1V331PCAP ALUM POLY HYB 330UF 35V SMD Panasonic Electronic Components |
3,469 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | ZU | Active | Hybrid | 330 µF | ±20% | 35 V | 11mOhm | 4000 Hrs @ 135°C | -55°C ~ 135°C | AEC-Q200 | Automotive | - | 720 mA @ 100 Hz | 4.8 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.504 (12.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
EEH-ZU1J101VCAP ALUM POLY HYB 100UF 63V SMD Panasonic Electronic Components |
2,934 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | ZU, Anti-Vibration | Active | Hybrid | 100 µF | ±20% | 63 V | 12mOhm | 4000 Hrs @ 135°C | -55°C ~ 135°C | AEC-Q200 | Automotive | - | 690 mA @ 100 Hz | 4.6 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.516 (13.10mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEH-ZU1H151PCAP ALUM POLY HYB 150UF 50V SMD Panasonic Electronic Components |
2,263 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | ZU | Active | Hybrid | 150 µF | ±20% | 50 V | 12mOhm | 4000 Hrs @ 135°C | -55°C ~ 135°C | AEC-Q200 | Automotive | - | 690 mA @ 100 Hz | 4.6 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.504 (12.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
EEH-ZU1V471VCAP ALUM POLY HYB 470UF 35V SMD Panasonic Electronic Components |
2,484 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | ZU, Anti-Vibration | Active | Hybrid | 470 µF | ±20% | 35 V | 9mOhm | 4000 Hrs @ 135°C | -55°C ~ 135°C | AEC-Q200 | Automotive | - | 825 mA @ 100 Hz | 5.5 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.673 (17.10mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEH-ZU1J151VCAP ALUM POLY HYB 150UF 63V SMD Panasonic Electronic Components |
2,511 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | ZU, Anti-Vibration | Active | Hybrid | 150 µF | ±20% | 63 V | 10mOhm | 4000 Hrs @ 135°C | -55°C ~ 135°C | AEC-Q200 | Automotive | - | 780 mA @ 100 Hz | 5.2 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.673 (17.10mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEH-ZU1J101PCAP ALUM POLY HYB 100UF 63V SMD Panasonic Electronic Components |
3,768 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | ZU | Active | Hybrid | 100 µF | ±20% | 63 V | 12mOhm | 4000 Hrs @ 135°C | -55°C ~ 135°C | AEC-Q200 | Automotive | - | 690 mA @ 100 Hz | 4.6 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.504 (12.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEH-ZU1H151VCAP ALUM POLY HYB 150UF 50V SMD Panasonic Electronic Components |
3,307 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | ZU, Anti-Vibration | Active | Hybrid | 150 µF | ±20% | 50 V | 12mOhm | 4000 Hrs @ 135°C | -55°C ~ 135°C | AEC-Q200 | Automotive | - | 690 mA @ 100 Hz | 4.6 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.516 (13.10mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEH-ZU1E561PCAP ALUM POLY HYB 560UF 25V SMD Panasonic Electronic Components |
3,332 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | ZU | Active | Hybrid | 560 µF | ±20% | 25 V | 8mOhm | 4000 Hrs @ 135°C | -55°C ~ 135°C | AEC-Q200 | Automotive | - | 870 mA @ 100 Hz | 5.8 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.661 (16.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEH-ZU1E471VCAP ALUM POLY HYB 470UF 25V SMD Panasonic Electronic Components |
3,232 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | ZU, Anti-Vibration | Active | Hybrid | 470 µF | ±20% | 25 V | 10mOhm | 4000 Hrs @ 135°C | -55°C ~ 135°C | AEC-Q200 | Automotive | - | 750 mA @ 100 Hz | 5 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.516 (13.10mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEH-ZU1E471PCAP ALUM POLY HYB 470UF 25V SMD Panasonic Electronic Components |
839 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | ZU | Active | Hybrid | 470 µF | ±20% | 25 V | 10mOhm | 4000 Hrs @ 135°C | -55°C ~ 135°C | AEC-Q200 | Automotive | - | 750 mA @ 100 Hz | 5 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.504 (12.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEH-ZU1H221VCAP ALUM POLY HYB 220UF 50V SMD Panasonic Electronic Components |
2,239 | - |
RFQ |
Scheda tecnica |
Tape & Reel (TR),Cut Tape (CT) | ZU, Anti-Vibration | Active | Hybrid | 220 µF | ±20% | 50 V | 10mOhm | 4000 Hrs @ 135°C | -55°C ~ 135°C | AEC-Q200 | Automotive | - | 780 mA @ 100 Hz | 5.2 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.673 (17.10mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
-Series-(THT-Tape-And-Box)-Photo-G12.jpg)
|
EEH-AZSH271UBCAP ALUM POLY HYB 270UF 50V T/H Panasonic Electronic Components |
3,497 | - |
RFQ |
Scheda tecnica |
Cut Tape (CT),Tape & Box (TB) | ZSU-A | Active | Hybrid | 270 µF | ±20% | 50 V | 13mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 740 mA @ 120 Hz | 3.7 A @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.657 (16.70mm) | - | Through Hole |
|
|
EEH-AZSJ181UBCAP ALUM POLY HYB 180UF 63V T/H Panasonic Electronic Components |
2,771 | - |
RFQ |
Scheda tecnica |
Cut Tape (CT),Tape & Box (TB) | ZSU-A | Active | Hybrid | 180 µF | ±20% | 63 V | 15mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 700 mA @ 120 Hz | 3.5 A @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.657 (16.70mm) | - | Through Hole |
|
|
EEH-AZSJ121UBCAP ALUM POLY HYB 120UF 63V T/H Panasonic Electronic Components |
3,361 | - |
RFQ |
Scheda tecnica |
Cut Tape (CT),Tape & Box (TB) | ZSU-A | Active | Hybrid | 120 µF | ±20% | 63 V | 19mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 600 mA @ 120 Hz | 3 A @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.500 (12.70mm) | - | Through Hole |
|
|
EEH-AZSE102UBCAP ALUM POLY HYB 1000UF 25V T/H Panasonic Electronic Components |
2,492 | - |
RFQ |
Scheda tecnica |
Cut Tape (CT),Tape & Box (TB) | ZSU-A | Active | Hybrid | 1000 µF | ±20% | 25 V | 11mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 800 mA @ 120 Hz | 4 A @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.657 (16.70mm) | - | Through Hole |
